Product Name:

ASUS ExpertCenter Pro ET900A X9-B-2000-3

Web Address:

www.asus.com

Model Number:

PRO ET900A X9-B-2000-2

EAN:

4711636605670

UPC:

199291605671

Package Type:

Retail

Warranty:

3 Years

Chipset:

AMD WRX90

CPU Interface:

Socket sTR5

Memory Total Slots:

8 (8-channel)

Memory Type:

DDR5 4800/5600/6400 MHz, ECC RDIMM

Memory Size:

64GB, 48GB, 32GB, 24GB, 16GB, 8GB ECC RDIMM

Total Expansion Slots:

7

Slot Location 1:

PCIe x16 slot (Gen5 x16 link)

Slot Location 2:

PCIe x16 slot (Gen5 x16 link)

Slot Location 3:

PCIe x16 slot (Gen5 x16 link)

Slot Location 4:

PCIe x16 slots (Gen5 x16 link)

Slot Location 5:

PCIe x16 slots (Gen5 x16 link)

Slot Location 6:

PCIe x16 slots (Gen5 x8 link)

Slot Location 7:

PCIe x16 slots (Gen5 x16 link)

Drive Bays External 5.25":

1 x 5.25” media bay for optional DVD-RW Slim optical drive and card reader

Drive Bays Internal 3.5":

4 x internal 3.5"/2.5" storage bays

S-ATA Controller:

4

SAS Controller:

• SlimSAS_1 slot supports PCIe 4.0 x4 mode NVMe device
• SlimSAS_2 slot supports PCIe 4.0 x4 mode NVMe device

M.2 Connector:

• M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
• M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
• M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
• M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)

On-Board LAN:

1 x Intel dual 10Gb Ethernet

Front I/O:

• 1 x USB 20Gbps Type-C port (15W, 5Vdc/3A)
• 2 x USB 5Gbps ports
• 1 x USB 2.0 port
• 1 x Headphone port
• 1 x Microphone port

Back Panel I/O Ports:

• 2 x USB4 (40Gbps) ports (2 x USB Type-C) (15W, 5Vdc/3A)
• 6 x USB 10Gbps ports (6 x Type-A)
• 1 x USB 2.0 port (1 x Type-A)
• 2 x Mini DisplayPort in
• 2 x RJ-45 LAN ports
• 2 x Audio jacks
• 1 x BIOS FlashBack button
• 1 x Clear CMOS button

Switch/LED:

• Front:
• 1 x Power Switch/LED
• 1 x HDD Access LED
• Rear:
• 1 x BIOS FlashBack button/LED
• 1 x Clear CMOS button
• Internal:
• Q-Code
• Q-LEDs (CPU; DRAM; VGA; BOOT)
• FlexKey button
• LN2 mode
• ReTry button
• Safe boot button
• Start button

Management Solution:

ASUS Control Center Express

Product Width:

230mm

Product Length:

500mm

Product Height:

579mm

Net Weight:

31.49Kg

Package Width:

50cm

Package Length:

57.9cm

Package Height:

23cm

Gross Weight:

37.57Kg

Special Features:

• Powered by AMD RYZEN Threadripper PRO 9000 and 7000 WX-series processors and up to 2 TB DDR5 ECC RDIMM for exceptional performance and reliability.
• Supports up to four NVIDIA RTX professional GPUs for powerful 2D/3D rendering and AI workloads.
• Seven PCIe 5.0 x16 slots for maximum expandability and futureproofing.
• Dual onboard 10 Gb LAN for ultra-fast, high-bandwidth, and low-latency connectivity.
• Supports up to four PCIe 5.0 M.2 slots and four SATA 6Gb/s ports for extensive storage options and high-speed data transfers.
• Two SlimSAS ports, ready for industrial-grade NVMe storage devices.
• Rich I/O options including both 40Gbps and 20Gbps USB Type-C, plus USB 20Gbps Type-A, for versatile connectivity.
• ASUS Control Centre Express empowers real-time IT monitoring and management for enhanced data protection.

Package Contents:

ExpertCenter Pro ET900A X9
