Product Name:

ASUS ROG STRIX GS-BE7200 Gaming Router Black - WiFi 7 - BE7200

Web Address:

www.asus.com

Model Number:

GS-BE7200

EAN:

4711636085052

Package Type:

Retail

Warranty:

3 Years

Device Type:

Router

Ports:

• WAN: 1 x 2.5Gbps
• LAN: 4 x 2.5Gbps

Standards:

• IEEE 802.11ax
• IEEE 802.11be
• IEEE 802.11a
• IEEE 802.11b
• IEEE 802.11g
• IEEE 802.11n
• IEEE 802.11ac
• IPv4
• IPv6

Transfer Rate:

• 2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps
• 5GHz BE: 5x5 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps

Network Architecture Types:

Infrastructure

Processor:

2.0GHz quad-core processor

Memory:

• 128 MB Flash
• DDR4 1GB RAM

Antenna Type:

6 x Internal

Frequency Range:

2.4GHz/5GHz

Security:

• AiProtection
• VPN
• WiFi Encryption:
• WPA/WPA2/WPA3 Personal
• WPA/WPA2/WPA3 Enterprise
• WPS
• Let's Encrypt
• DNS-over-TLS
• SSH
• Security Scan
• Firewall
• Maximum Firewall Keyword Filter: 64
• Maximum Firewall Network Service Filter: 32
• Maximum Firewall URL Filter: 64

Management:

• Configuration Backup and Restore
• Diagnosis Tools
• Feedback System
• System Log
• New Device Connect Notification
• Login Captcha
• Connection Diagnosis
• Auto Firmware Update

VPN Support:

• Instant Guard
• VPN Client L2TP
• VPN Client Open VPN
• VPN Client PPTP
• VPN Client WireGuard
• VPN Server IPSec
• VPN Server Open VPN
• VPN Server PPTP
• VPN Server WireGuard
• VPN Fusion

LED indicators:

• WiFi
• WAN
• SYSTEM

Button:

• Power
• WPS
• Reset

Input Power:

• AC Input: 110V-240V(50-60Hz)
• DC Output: 12V with max. 2.5A current

Product Width:

182.3mm

Product Length:

80mm

Product Height:

207mm

Package Width:

24.1cm

Package Length:

27.3cm

Package Height:

9.5cm

Net Weight:

0.64Kg

Gross Weight:

1.39Kg

Special Features:

• Dual-band WiFi 7 throughput of up to 7200Mbps with MLO and 4K-QAM.
• 12.5G wired capacity with four 2.5G LAN ports and one 2.5G WAN port.
• Six internal antennas and boosted 5GHz range, delivering up to 15% better throughput at long distances than standard 5GHz 4T4R routers.
• ROG-exclusive Gaming Network with Adaptive QoE prioritizes game traffic in real time, keeping gameplay smooth and lag-free - even under heavy network load.
• Easy IoT device and VPN subnetwork setup, parental controls, and instant connections with Smart Home Master.
• Advanced triple-level network security with AiProtection and pre-installed VPN support.
• WiFi 7-enhanced AiMesh enables a secure and extendable network for compatible ASUS routers.

Package Contents:

• WiFi7 Dual-Band router
• ROG RJ-45 cable
• Power adapter
• Quick Start Guide
• Warranty card

Keywords:

• Router
• Wi-Fi 7
• BE7200
• MU-MIMO
