Product Name:

Gigabyte H410M H V2 (Socket 1851//H810/DDR5/S-ATA 6Gb/s/Micro ATX)

Web Address:

www.gigabyte.com

Model Number:

H810M GAMING WIFI6

EAN:

4719331869090

UPC:

889523047941

Package Type:

Retail

Warranty:

3 Years

BIOS:

• 1 x 256 Mbit flash
• Use of licensed AMI UEFI BIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Chipset:

Intel H810 Express

CPU Interface:

Socket 1851

CPU Support:

https://www.gigabyte.com/Motherboard/H810M-GAMING-WIFI6/support#support-cpu

RAM Technology:

DDR5 (Dual Channel)

RAM Slots:

2 x 288-pin

RAM Speeds:

Up to DDR5 6400

Max. Memory Support:

128GB

PCI Express 4.0 x16:

1

PCI Express 3.0 x1:

1

S-ATA 6Gb/s Port(s):

4

RAID:

Raid 0/1/5/10

M.2 Socket(s):

1

LAN Speed:

Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

Wireless NIC:

Wi-Fi 6

Wireless Technology:

WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands

Bluetooth:

v5.3

On-Board Audio:

• Realtek Audio CODEC
• High Definition Audio
• 2/4/5.1/7.1-channel

On-Board Video:

Processor with integrated graphics is required

Back PS/2 Keyboard/Mouse Port:

1

Back USB 2.0 Port(s):

5

Back USB 3.2 Port(s) Type-A Gen 1:

1

Back HDMI Port(s):

1

Back DisplayPort(s):

1

Back LAN Port(s):

1

Back Audio Jack(s):

3

24-pin ATX Power:

1

8-pin ATX Power:

1

USB 2.0 Header(s):

2

USB 3.2 Header(s) Gen 1:

2

COM Port Header(s):

1

Front Panel Audio Connector:

1

TPM Header(s):

1

S/PDIF Out Header(s):

1

Internal Other Port(s):

2 x addressable RGB Gen2 LED strip headers

Form Factor:

Micro ATX

Product Width:

215mm

Product Length:

244mm

Package Width:

26.5cm

Package Length:

27cm

Package Height:

7cm

Gross Weight:

1.06Kg

Special Features:

• Supports Intel Core Ultra processors (Series 2).
• WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation.
• EZ-Latch: PCIe x16 Slot with Quick Release Design.
• M.2 EZ-Latch Plus: Screwless installation for M.2 SSDs.
• Friendly UI: Multi-Theme, and Q-Flash Auto Scan in BIOS and SW.
• Ultra-Fast Storage: PCIe 4.0 x4 M.2 slots.
• Efficient Thermal: VRM Thermal Armor Advanced and M.2 Thermal Guard.
• Fast Networking: 2.5GbE LAN and Wi-Fi 6 802.11ax.
• Extended Connectivity: HDMI, DisplayPort.

Package Contents:

• Motherboard
• Manual
• Quick Installation Guide
• 1 x Antenna
• 2 x SATA cables
• Pack of M.2 thick/thin rubber pads
