ASUS 1851 ROG MAXIMUS Z890 EXTREME
SKU: 125803

ASUS 1851 ROG MAXIMUS Z890 EXTREME



Product Group:

Motherboards

Manufacturer:

ASUS

SKU:

125803

Product Specifications

Product Name:

ASUS ROG MAXIMUS Z890 EXTREME (Socket 1851/Z890/DDR5/S-ATA 6Gb/s/Extended ATX)

Web Address:

www.asus.com

Model Number:

ROG MAXIMUS Z890 EXTREME

EAN:

4711387754153

UPC:

197105754157

Package Type:

Retail

Warranty:

3 Years

BIOS:

2 x 256 Mb Flash ROMUEFI AMI BIOS

Chipset:

Intel Z890

CPU Interface:

Socket 1851

RAM Technology:

DDR5 (Dual Channel)

RAM Slots:

4 x 288-pin

RAM Speeds:

Up to DDR5 8400+ (O.C.)

Max. Memory Support:

192GB

PCI Express 5.0 x16:

2

PCI Express 4.0 x4:

1

S-ATA 6Gb/s Port(s):

4

RAID:

Raid 0/1/5/10

M.2 Socket(s):

3 x PCIe Gen 5.0 x43 x PCIe Gen 4.0 x4

On-Board LAN:

1 x Intel 2.5Gb Ethernet1 x Marvell AQtion 10Gb Ethernet

Wireless NIC:

Wi-Fi 7

Wireless Technology:

2x2 Wi-Fi 7 (802.11be)Supports 2.4/5/6GHz frequency bandSupport Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate.

Bluetooth:

v5.4

On-Board Audio:

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082

On-Board Video:

Processor with integrated graphics is required

Back USB 10Gbps Port(s) Type-A:

5

Back USB 10Gbps Port(s) Type-C:

2

Back USB 20Gbps Port(s) Type-C:

1

Back Thunderbolt 5 Port(s):

2

Back HDMI Port(s):

1

Back LAN Port(s):

2

Back Audio Jack(s):

2

Back S/PDIF Output Port(s):

1

Back Other Port(s):

1 x Wi-Fi Module

Back Button(s):

1 x BIOS FlashBack1 x Clear CMOS

24-pin ATX Power:

1

8-pin ATX Power:

2

PCIe Power Connector(s):

1 x 8-pin

USB 2.0 Header(s):

2

USB 5Gbps Header(s):

2

USB 10Gbps Header(s):

1

USB 20Gbps Header(s):

1

Front Panel Audio Connector:

1

Internal Other Port(s):

1 x 6-pin ARGB Gen 2 header to support2 x ARGB Gen 2 headers2 x Addressable Gen 2 header18 x ProbeIt Measurement Points1 x Thermal Sensor header

Internal Button(s):

4 x BCLK1 x BIOS Switch1 x FlexKey1 x ReTry1 x Safe Boot1 x Start

Form Factor:

Extended ATX

Product Width:

277mm

Product Length:

305mm

Package Width:

32cm

Package Length:

37.6cm

Package Height:

12.5cm

Gross Weight:

5.44Kg

Special Features:

Extreme OC Kit.Extreme Engine Digi+ASUS Q-DesignASUS Thermal SolutionASUS Thermal SolutionAura SyncDual BIOSFull Colour 5-inch LCD DisplayROG M.2 PowerBoostFront Panel USB 20Gbps with Quick Charge 4+ Support

Package Contents:

Motherboard1 x 1-to-3 ARGB splitter cable1 x 1-to-2 ARGB splitter cable2 x 1-to-4 fan splitter cable2 x ROG weave SATA 6G cable packages1 x 3-in-1 Thermistor cables pack1 x ROG DIMM.2 with heatsink1 x M.2 pad package for ROG Q-DIMM.22 x Thermal pad for ROG Q-DIMM.22 x Thermal pad for M.2 221101 x DDR5 Fan holder1 x ASUS WiFi Q-Antenna1 x Q-connector1 x ROG logo plate sticker1 x ROG screwdriver1 x ROG stickers1 x ROG VIP card2 x M.2 Q-Slide packages6 x M.2 backplate rubber packages1 x ROG Bottle Opener1 x USB drive with utilities and drivers 1 x Quick start guide

Keywords:

MotherboardZ890DDR5WiFiBluetooth
